Modular Palletizing Solutions with the Warsonco WSC-MD30 Max
The WSC-MD30 Max palletizing robot is available in two versions: with lifting column (lifting range 1200–2200 mm, 30 mm/s) and without lifting column (fixed height 1600mm). Depending on the gripper and product size, the versions allow an approximate stacking height of 1600 mm without and 2600 mm with lifting column. Both versions operate on AC 380 V, 3500 W. Pallet sizes: 1200×1000 mm / 1200×800 mm. The mobile unit can be moved by two persons, total weight approx. 350 kg (with lifting column).
Control is provided via touch panel, Web terminal or industrial control host. Graphical programming (drag & drop) and SDKs for C#/Python/Java enable fast commissioning. Interfaces: Modbus, TCP/IP, RS-485, digital I/Os; optional Profinet, EtherCAT, Ethernet/IP. The integrated WarsoncoWarsonco intelligent palletizing software allows easy configuration without programming knowledge, supporting AI visual adaptation.
Ideal for food, medicine, daily chemicals, logistics and production line end palletizing, with multi-level palletizing for variable product sizes – efficient, flexible and easy to integrate.
Highlights
Fast Deployment and Easy Operation
Basic programming in just 1 hour
Operators can master system operation in 30 minutes and perform simple programming within 1 hour, enabling rapid deployment and efficient production line modifications. Its lightweight, all-in-one design allows quick installation and task configuration, while the IP54 protection rating, 0–55°C operating temperature range, and strong anti-interference performance ensure reliable operation in demanding industrial environments.
Integrated Safety and Smart Connectivity
Designed for safe human-machine collaboration
The system supports integration with light curtains, laser scanners, and physical safety barriers, featuring zone alarms and instant stop functions to ensure workplace safety. TCP/IP communication enables seamless connectivity with MES platforms, PLCs, and smart factory systems, simplifying integration into modern production environments.
Compact Design with Powerful Performance
30 kg payload and palletizing heights up to 2,600 mm
Despite its compact footprint, the system delivers outstanding performance with a payload capacity of up to 30 kg, a 1,900 mm working radius, and palletizing heights of up to 2,600 mm. With palletizing speeds of up to 9 pieces per minute and repeatability of ±0.04 mm, it provides precise, reliable, and continuous operation while maximizing floor space efficiency.
